The EEPROM interface is a crucial feature in the ATmega328 microcontroller, providing 1024 bytes of non-volatile memory for storing configuration data, calibration values, and other persistent information that must survive power cycles. Unlike RAM, EEPROM retains data without power, making it ideal for saving user settings, device parameters, sensor calibration data, and system logs. This repository covers the register-level configuration, practical usage examples, and important considerations for implementing reliable EEPROM operations in embedded systems.
|
Tip If you're looking to better understand how to navigate and use my GitHub repositories — including exploring their structure, downloading or cloning projects, submitting issues, and asking questions, |
|
|
|
Important Begin your embedded systems journey with clarity and purpose. This episode outlines a structured roadmap for mastering microcontrollers, communication protocols, hardware design, and project development. |
|
|
|
Caution It is absolutely critical that you carefully read every single word of this document, line by line, to ensure you don't miss any details. Nothing can be overlooked. |
||
✅ Unsigned integers: uint8_t, uint16_t, uint32_t
✅ Signed integers: int8_t, int16_t, int32_t
✅ Floating-point: float (IEEE 754 single-precision)
✅ Byte arrays: Block read/write operations
✅ Update functions that compare before writing
✅ Extends EEPROM lifespan by avoiding unnecessary write cycles
✅ Critical for applications with frequent data updates
✅ Atomic erase-and-write operations (hardware controlled)
✅ Little-endian byte order for multi-byte values
✅ Protection against partial writes during power loss
✅ Direct write for initial programming
✅ Smart update for runtime modifications
✅ Block operations for efficient array storage
✅ Format function to reset EEPROM to blank state
| Parameter | Value |
|---|---|
| Memory Size | 1024 bytes (1 KB) |
| Address Range | 0x0000 to 0x03FF (0 to 1023) |
| Write Time | ~3.3 ms per byte (typical at 25°C) |
| Write Endurance | 100,000 cycles minimum per location |
| Data Retention | 20 years at 85°C, 100 years at 25°C |
| Byte Order | Little-endian (LSB first) |
| Operation Mode | Atomic erase-and-write |
| Read Speed | ~4 CPU cycles (fast) |
Here you'll find a collection of useful links and videos related to the topic of AVR microcontrollers.
EEPROM Overview
├── [API_Reference]
│ ├─ Files — e2prom.h / e2prom.c
│ ├─ Write Functions — uint8, uint16, uint32, float, int8, int16, int32, block
│ ├─ Read Functions — uint8, uint16, uint32, float, int8, int16, int32, block
│ ├─ Update Functions — Wear-leveling versions of write (compare before write)
│ ├─ Utility — Format (erase entire EEPROM)
│ └─ Purpose — High-level EEPROM interface for storing multiple data types
│ with automatic wear-leveling and endurance optimization
|
└── Registers
├─ [EEAR / EEARH / EEARL] — EEPROM Address Register — 10-bit address (0-1023)
├─ [EEDR] — EEPROM Data Register — 8-bit data for read/write operations
└─ [EECR] — EEPROM Control Register — Controls operations and modes
├─ EERE — EEPROM Read Enable
├─ EEPE — EEPROM Program Enable (write trigger)
├─ EEMPE — EEPROM Master Program Enable (safety mechanism)
├─ EERIE — EEPROM Ready Interrupt Enable
└─ EEPM1:EEPM0 — Programming mode selection (erase+write, erase, write)
Tip
The resources are detailed in the sections below.
To access any of them, simply click on the corresponding blue link.
-
Comprehensive documentation covering all EEPROM control registers (EEAR, EEDR, EECR), programming modes, write/read operation sequences, timing requirements, atomic access considerations, interrupt handling, data protection strategies, and wear-leveling techniques. Includes timing diagrams, practical examples, and troubleshooting guidelines.
-
This section provides detailed descriptions of the functions in the
e2prom.hande2prom.cfiles for handling EEPROM operations on the ATmega328 microcontroller. Each function is designed to store and retrieve different data types (unsigned integers, signed integers, floats, and byte arrays) with support for wear-leveling through update functions. These APIs simplify EEPROM management by providing type-safe interfaces for reading, writing, and updating persistent data, making it easier to implement configuration storage, data logging, and calibration value retention in your projects.
AVR, EEPROM
├── [aKaReZa 131 - AVR, EEPROM - PART A]
│ ├─ Concept — AVR internal EEPROM structure and use cases.
│ ├─ Registers — EEAR, EEDR, EECR bit-by-bit review.
│ ├─ Functions — uint8_write(), uint16_write(), uint32_write().
│ ├─ Endianness — Storage order considerations.
│ ├─ Type Punning — Advantages and safe usage.
│ └─ Project — Building and testing EEPROM write routines.
│
└── [aKaReZa 134 - AVR, EEPROM - PART B]
├─ Float — Implementing float_Write() for floating‑point storage.
├─ Block — Writing arrays and strings with block_Write().
├─ Read — Functions for reading multiple data types.
├─ Update — Smart update functions to reduce wear.
├─ Timing — Execution‑time analysis and comparisons.
├─ Signed — Write/Read/Update for signed data types.
└─ Format — Erasing the entire EEPROM memory.
|
Explore the internal EEPROM of AVR microcontrollers—a powerful feature for permanent data storage across resets and power cycles. This tutorial provides a bit-by-bit review of EEAR, EEDR, and EECR registers, and guides you through writing functions like |
|
|
Continue exploring advanced EEPROM data storage on AVR. This episode covers writing floats and arrays, reading multiple data types, implementing smart Update functions to reduce wear, analyzing execution time, and adding full‑memory formatting. A solid foundation for building efficient and reliable data‑persistence systems in embedded projects. |
|
